Ex: Dimensioning 3
The objective of this exercise is to practice dimensioning a part.
You will need the worksheet in your book to complete this exercise.
When the function of a part is unknown, correctly dimensioning the part is not a unique solution. When you have dimensioned your part, click on the figure to reveal the solution.
