Ex: Dimension placement



The objective of this exercise is to get familiar with the proper placement of dimensions.



You will need the worksheet in your book to complete this exercise.



Consider the incorrectly dimensioned object shown. There are 6 types of dimensioning mistakes. List them and then dimension the object correctly. Click on the figure to reveal the solution.



Dimension Placement
