Ex: Feature dimensions 4
You will need your textbook worksheet for this exercise.
Fill in the feature size if
- drill = 10 mm
- counterbore drill and max. countersink dia. = 20 mm
- countersink angle = 90o
- counterbore depth = 12 mm
- blind hole depth = 25 mm
- chamfer size is 2 mm and angle is 45o
