Instantaneous Center of Zero and Known Velocities - Example Problem 4.4-6

The rectangular plate is confined by rollers within slots at A and B.  When θ = 20^o, point B is moving at v_B = 10 m/s.  Determine the velocity of points C and D at this instant.  The dimensions of the plate are a = 100 mm and b = 50 mm.

Given:

• θ = 20^o
• v_B = 10 m/s
• a = 0.1 m
• b = 0.05 m

Find: v_C, v_D

The following video walks you through the solution to this problem. It is suggested that you try solving the problem first and then, if you have difficulties with the solution, watch the video for help.

Draw the velocity direction for point A and then locate the IC for the plate. Click on the image when done.
